Report item
Item specifics
  • Package: Yes
  • Brand Name: BOYA
  • Communication: Wired
  • Model Number: SR-AX100
  • Use: Interviewing
  • Style: Audio Mixer
Product Description

BY-WM635

Saramonic SR-AX100 Pro Universal Audio Mixer Adapter with 3.5mm Inputs for DSLR Camera and Camcorder Microphones

Overview
The Saramonic SR-AX100 allows you two microphones, wireless receivers and more to any DSLR camera or compact camcorder that feature a 3.5mm aux mini-jack input. The SR-AX100 features a passive circuit making it virtually noise free and does not require batteries. It can be used for interviewing, small talk show, broadcast, family party and micro movie. Voice from -12dB to -6dB are needed when recording via microphones into cameras or camcorders. Sometimes, the voice needs to be attenuated with the Saramonic SR-AX100 audio adapter to make the best sound. The Saramonic SR-AX100 enables you to control the voice by knobs and turns the mono into stereo.

Highlights
Inputs: One 3.5mm (1/8") stereo and two 3.5mm (1/8") mono inputs
Output:One 3.5mm (1/8") stereo output
Dual control knobs; Mono/Stereo switch
Universal camera/camcorder attachment via standard hot-shoe. Also features three integrated mounting shoes for microphones, recorders, lights, etc.
Passive circuit requires no batteires


Technical Specifications
Inputs: One 3.5mm (1/8") stereo and two 3.5mm (1/8") mono
Output: Stereo 3.5mm aux mini-jack
Input Level: -35dBu
Frequency Response: 10Hz to 100 kHz (+/- 1.5dB)
Construction: Aluminum
Dimensions (LxWxH): 7.6x5.9x5.5cm
Weight: 153g (5.4 oz)
Warranty: 1 Year

Attention: The Saramonic SR-AX100 is not compatible with microphones that can\'t be installed with battery.





Fulfilling Various Needs
The Saramonic SR-WM4C is a compact and lightweight VHF wireless lavalier microphone system - the perfect audio solution for recording simply and easily, free from the limit of distance. The SR-WM4C is ideal for film making, conducting broadcast interviews and business presentations - or any other need that requires portability and great sound quality. The Saramonic audio adapter SR-AX100 can work with two pairs of the SR-WM4C microphone system. The audio mixer enables more than one pair lavalier microphone system to work at the same time for interviewing and talk show. It allows 2 men to talk at the same with Saramonic SR-AX100 audio adapter. The configuration can turn the mono into stereo voice, it combines two human beings\' sound into your camera at the same time with a Saramonic audio mixer SR-AX100. Match and work perfectly in interviewing, small talk show, broadcast, family party and micro movie. (see the configuration images below)




112
Packaging Details
  • Unit Type: piece
  • Package Weight: 0.5kg (1.10lb.)
  • Package Size: 15cm x 10cm x 10cm (5.91in x 3.94in x 3.94in)
